LeeBoy 8510b - Hydraulic 2 of 4

9
9-27
Schematics
LeeBoy Model 8510B Conveyor Paver
Hydraulic 2 of 4
RC1
LB1
LC2VPA2VRB2VPA3VRB3PSRB1
VPA1RA2RB2LA3LB3PB4VB1
TA4
850001
MANIFOLD,
AUGERS & 2
SPEED
CBL
CRL
CBR
CRR
A
B
1500 PSI
I
CONVEYOR RAISE
EXTENSION (RIGHT)
SCREED CUTOFF (LEFT) CUTOFF (RIGHT) SIDEWING AUGER (LEFT) AUGER (RIGHT)
A
B
A
B
A
B
A
B
A
B
A
B
A
B
A
B
A
B
P
T
2200 PSI
(LEFT)
EXTENSION
910122
MANIFOLD, HOPPER
WING SEQUENCE
910170 CUTOFF CYLINDER (LEFT) CYL, HYD, 2.50X4.00X1.25 ROD
910170 CUTOFF CYLINDER (RIGHT) CYL, HYD, 2.50X4.00X1.25 ROD
840020
HOPPER LIFT CYLINDER
CYL, HYD, 3.00X12.00X1.25 ROD
851192
EXTENSION CYLINDER (RH)
CYL, HYD.,
2.00X12.00X30.00X1.25
851191
EXTENSION CYLINDER (LH)
CYL, HYD.,
2.00X12.00X30.00X1.25
851436 SCREED LIFT CYL CYL, HYD, 2.00X12.00X1.00 ROD
851436 SCREED LIFT CYL CYL, HYD, 2.00X12.00X1.00 ROD
610110
SIDEWING CYLINDER
CYL, HYD, 2.00X8.00X1.00 ROD
610110
SIDEWING CYLINDER
CYL, HYD, 2.00X8.00X1.00 ROD
851161
VALVE ASSY, 9 SECTION
Figure 9-13
