LeeBoy 8510b - Main Dash Panel (Continued)

5-6 LeeBoy Model 8510B Conveyor Paver
Component Location
Main Dash Panel (continued)
1 4 5
6
7
8
9
101112131415161718
19
20
21
2 3
Main Dash Panel (continued)
Figure 5-2
17 - Left Conveyor Automatic/Manual
18 - Throttle Switch
19 - Ignition
20 - Plus One Indicator Light
21 - Parking Brake
