5
LeeBoy Model 8510B Conveyor Paver 5-5
Component Location
Table 5-2. Main Dash Panel
ITEM NO. CONTROL NAME FUNCTION
1 3 in 1 Gauge:
Tach, Oil, Water Temp
Shows engine RPM, engine lubricating oil pressure, and engine water
temperature
2 Check Engine Light Indicates an engine fault when illuminated.
NOTE: Refer to engine operator’s manual and an authorized LeeBoy Dealer.
3 Fuel Gauge Indicates amount of fuel in fuel tank
4 Hourmeter Meter monitors the working hours of the machine
5 Voltmeter Indicates battery voltage
6 Grade Control/Slope When switch is in the GRADE position, power is only on when joystick is in
forward position.
NOTE: When machine is equipped with SLOPE, power is only on when the
joystick is in the FORWARD position. With the joystick in NEUTRAL
and the switch in SLOPE, all power is turned off.
7 Left Sonic Automatic
Auger
Selects ON or OFF for the automatic operation of Left Auger.
NOTE: Top position turns ON the Left Auger. Bottom position turns OFF
the Left Auger. The hydraulic valve needs to be actuated for the
automatic augers to work
8 Right Sonic Automatic
Auger
Selects ON or OFF for the automatic operation of Right Auger.
NOTE: Top position turns ON the Right Auger. Bottom position turns OFF
the Right Auger. The hydraulic valve needs to be actuated for the
automatic augers to work
9 Front Work Lights Used to turn the work lights ON or OFF
10 Rear Work Lights Used to turn the rear work lights ON or OFF
11 High/Low Gear Used to change machine speed.
Place switch in HIGH position for travel. (When in TRAVEL red 2-SPEED
Light (Figure 5-2. 12) will illuminate.)
NOTE: High speed is only for traveling. Never pave in HIGH speed.
12 High/Low Light Illuminates to indicate when HIGH/LOW switch is in the HIGH position
13 Spray Down Used to turn on the Spray Down System.
Set switch to SPRAY DOWN position to turn spray system on.
14 Beacon Light Used to turn the beacon light on or off.
Set switch to BEACON position to turn the Beacon light on.
15 Horn Press button to sound the horn
16 Right Conveyor
Automatic/Manual
Selects automatic or manual override for right conveyor.
Center is OFF position.
For Automatic operation set switch to AUTOMATIC position.
MANUAL position provides override.
