LeeBoy 8510b - Specification Charts

4-4 LeeBoy Model 8510B Conveyor Paver
Specications
Table 4-1. Dimension Specications (See Figure 4-1)
ITEM SPECIFICATION
Overall Length 12’ 5.5” (380 cm)
Overall Height 8’ 6” (259 cm)
Overall Width (hopper wings in) 8’ 6” (259 cm)
Overall Width (hopper wings out) 10’ (305 cm)
Paver Weight (with screed) 17,300 lbs (7,847kg)
Basic Paving Width 8’ (2.44m)
Maximum Paving Width 15’ (4.57m)
Screed Plate Material 3/8” (9.5mm) AR400 Steel
Main Screed Wear Plate 15” (.38m)
Extensions Width of Wear Plate 7” (17.8cm)
Extensions Length 3’6” (1.07m)
Walkway Width 12” (30.5cm) W/Extension
Table 4-2. Performance Specications
ITEM SPECIFICATION
Travel Speed 240 FPM (0.73 KPM)
Paving Speed 140 FPM (0.37 KPM)
Coverage: Basic Screed Width 8’ (244 cm)
Coverage: Maximum Screed Width 15’ (457 cm)
Table 4-3. Kubota Tier 3 Engine Specications
ITEM SPECIFICATION
Manufacturer and Model Kubota, V3600-T-E3B
Emission Regulation Tier 3 / Stage III A
Type Vertical 4-cycle Liquid Cooled Diesel
Number of Cylinders 4
Bore, Stroke, and Displacement 3.86” (98 mm) ; 4.72” (120 mm); 220.9 in
3
(3.62 L)
Combustion System Direct Injection
Intake System Turbocharged
Power Rating kW - HP 63.0 kW - 84.5 HP
Maximum Speed 2400 to 2500 rpm
Fuel Filter Type Kubota Diesel
Specification charts
The specications provided in this section are
applicable to the LeeBoy Model 8510B Conveyor Paver.
Included in this section are specications for paver
weights, dimensions, performance, and torque values for
both metric and standard inch fasteners.
Replace original equipment only with
LeeBoy approved components.
