LeeBoy Model 8510B Conveyor Paver 4-5
Specications
Table 4-4. CAT Tier 3 Engine Specications
ITEM SPECIFICATION
Manufacturer and Model CAT, C3.4 T NA 83 HP
Emission Regulation Tier 3 / Stage III A
Type I-4, 4-Stroke-Cycle Diesel, Liquid Cooled
Number of Cylinders 4
Bore, Stroke, and Displacement 3.70” (94 mm) ; 4.72” (120 mm); 201 in
3
(3.30 L)
Combustion System Direct Injection
Intake System Turbocharged
Power Rating bkW - HP 73.7 bkW - 83.1 HP
Maximum Speed 2500 rpm
Fuel Filter Type CAT Diesel
Table 4-5. Machine System Capacity Specications
ITEM SPECIFICATION
Kubota CAT
Engine Lubrication Oil - Rell capacity 15.0 quarts (14.2 L) 10.6 quarts (10.0 L)
Engine Lubrication Oil - Pan capacity 13.9 quarts (13.2 L) 9.5 quarts (9.0 L)
Hydraulic Oil Reservoir 40 gal (151.40 L)
Torque Hubs 32 oz. (0.355 L) each
Fuel 20 gal (75.70 L)
Propane One (1) 20 lb tank
Anitfreeze Glycol based, Rd, Extended Life, 3.65 gal (13.8 L)
Table 4-6. Electrical Specications
ITEM SPECIFICATION
Kubota CAT
Battery One, Maintenance Free
Battery Ampere Hour Rating 1125 CCA
Battery Voltage 12 Volts
Alternator Type and Voltage 12 Volt, negative ground
Alternator Output Amperage 60 Amps 63 Amps
Alternator Fan Belt Tension
Automatic belt tension mechanism keeps serpentine
belt under tension at all times
Starter Manufacturer Denso
Starter Voltage and Type 12 Volt, negative ground
Table 4-7. Hydraulic Pressures Specications
ITEM SPECIFICATION
Drive 4500 PSI (310 Bar)
Conveyors 2500 to 2600 PSI (172 to 179 Bar)
Augers and Cylinders 2600 to 2700 PSI (179 to 186 Bar)
