LeeBoy 8510b - Electrical 1 of 6

9-3
9
Schematics
Electrical 1 of 6
987654321
18 17 16 15 14 13 12 11 10
POWER INPUT
8510 PAVER FUSE DIAGRAM
1
2ORANGE BLACK NEUTRAL START
3RED 16 GA IGNITION
4YELLOWSTART
5ORANGEGLOW PLUGS
6BROWN OIL PRESSURE
7BLUEENGINE TEMP
8WHITE CHECK ENGINE
9TAN TACH
10 YELLOW BLACK THROTTLE DEC
11 RED ORANGE FUEL LEVEL
12 WHITE BLACK THROTTLE INC
1
2
RED 12 GA
3BLACK 12 GA
4
SEE
ENGINE
HARNESS
PLUG
SEE
ENGINE
HARNESS
POWER
PLUG
T
FUSE BLOCK 18 GANG
(PARTIAL)
SWITCH LEFT CONVEYOR
REF ONLY
SWITCH SPRAY
DOWN
REF ONLY
Figure 9-1
LeeBoy Model 8510B Conveyor Paver
LeeBoy Model 8510B Conveyor Paver
