LeeBoy Model 8510B Conveyor Paver 10-123
Illustrated Parts List (IPL)
Generator Parts List
Item
No. Part Number Qty. Description Remarks
1 987893 1 Generator, Hyd., Assy Image may not be visually accurate
2 988176 1 Generator, Only
3 986994 1 Motor, Hyd, Generator
4 Reference 1 Seal
5 985880 1 Breaker, Main
6 985138-03 1 Power Cord, Bulkhead to Control Box
7 985826 1 Harness, Electric Heat, Gen. to Bulkhead
8 986992 1 Manifold, Generator, w/Flow Control
— 986658 1 Capacitor, Generator, 40 uF Not Shown
— 1002148 1 Capacitor, Generator, 30 uF Not Shown
— 1002147 1 Capacitor, Generator, 25 uF Not Shown
— 1002146 1 Capacitor, Generator, 20 uF Not Shown
— 987894SRV 1 Coupling Assy, Motor To Generator, 28 mm Not Shown
— 1002454 1 Coupling Half, 3 Jaw, 24 mm Not Shown
