LeeBoy Model 8510B Conveyor Paver 10-5
Illustrated Parts List (IPL)
Sprocket Drive Track System (4 Roller Undercarriage) Parts List
Item
No. Part Number Qty. Description Remarks
2 851101P 1 Track Assy, One Side, w/Poly Pads
3 851102 1 Chain Rail, Track Drive
4 986807 1 Torque Hub, 47.6:1, w/Brake
5 1003052 1 Sprocket, Track Drive
6 81201 7 Washer, Flat, SAE, .625
7 80983 7 CSHH, .625-11 x 2.00 GR8
8 81170 12 CSHH, .625-11 x 1.25 GR8
9 851566 1 Track Roller, B/1
10 811328 20 Washer, Lock, M12
11 811330A 8 CSHH, M12-1.50 x 50mm
12 811326 4 Track Roller, B/O
13 811330 12 CSHH, M12-1.50 x 40mm
14 1001589 1 Idler, Track Front
15 1003072 1 Assy, Weldment, Undercarriage, L.H.
16 1003073 1 Assy, Weldment, Undercarriage, R.H.
17 811329A 1 Yoke, Track Idler
18 870307 1 Hair Pin Cotter, .177
19 811331 1 Cyl, Hyd, Track Tensioner
20 851644 1 Breather, Track Tensioner Cyl.
21 811331-01 1 Seal Kit, Hyd. Cyl.
22 851104 A/R Track Pad, Poly
22a 811304 A/R Cast Track Pad 33 per side
— 851101 A/R Track Assy, Cast Not Shown
22b 983166-02 A/R Track Pad, Poly, Heavy Duty
— 983166-03 A/R Chain Rail, Track Drive, Heavy Duty Not Shown
— 983166-04 A/R Pin, Track Link, Master, Heavy Duty Not Shown
— 983166-05 A/R Kit, Track, Heavy Link Not Shown
— 983166-06 A/R CSHH, 135mm, Track Pad Bolt Not Shown
24 811312 A/R Link Kit, Track Repair
25 851460 A/R Bushing, Track Link, Short
26 811314
A/R Bushing, Track
27 811307 A/R Pin, Track Link, Plain
28 811306 A/R Pin, Track Link, Master
29 811310 A/R Spacer, Track Link Bushing
30 811308 A/R CSHH, Track Pad
31 811309 A/R Nut, Track Pad Cap Screw
32 2404-10-8 1 Adapter, Hyd. Hose
33 984283SRV 1 Push Roller Assy, Swivel
