LeeBoy Model 8510B Conveyor Paver 10-35
Illustrated Parts List (IPL)
Cat Engine Parts List
Item
No. Part Number Qty. Description Remarks
— 1002917 1 Cat C3.4t Tier3 Not Shown
— 1002917-33 1 C3.4 Sn# Cjr Oper Manual Not Shown
1 1002917-01 1 Radiator/Oil Cooler Combo
2 1002917-02 4 Bottom Radiator Mount
3 1002917-03 1 Guard, Fan Rd 18.625 2.00"ID
4 1002917-04 1 Puller 17.32/8-8/25/Pag/3Hl/
5 1002917-05 1 F/W Coupling w/Pmp
— 1002917-38 1 Coupling, Pump Drive Coupler and Hardware Only
6 1002917-06 1 800 Ex Elbow w/Flange 3Hole
7 1002917-07 1 Flex Tube 2.00 ID x 2.50 OD x 4.50 L
8 1002917-08 1 Left Mufer Support
9 1002917-09 1 Right Mufer Support
10 1002917-10 1 Bracket, Front Mount
11 1002917-11 1 Leg, Right Rear
12 1002917-12 1 Hose, Upper 42496683
— 1002917-13 1 Harness, Cat Paver Not Shown
13 1002917-14 1 Transition Tube 2.50 x 3.00
14 1002917-15 1 Bracket Top Left Radiator
15 1002917-16 1 Leg, Left Rear
16 1002917-17 1 Bracket, Throttle
17 1002917-18 1 Lever, Throttle
18 1002917-19 1 Bracket, Top Right Radiator
19 1002917-20 1 804 Fan Spacer
20 1002917-21 1 Hose, Lower Radiator
— 984909-12 1 Water Temp Sender M16 x 1.50 Not Shown
— 39081 1 Hyd Oil Pressure Sender Not Shown
— 1002917-22 1 Temp Switch 240F .250 Nptf Not Shown
— 1002917-23 1 Three Thread Plug Seal Not Shown
21 986537-14 4 Isolator, 8515
— 984909-10 1 FITT
Not Shown
— 38826 1 FITT, Bspp To Pipe, .250-18 Not Shown
— 1002917-24 1 Tee Female Pipe .125 Not Shown
— 1002917-25 2 Adapter, .500-20 to .250-18 SAE Not Shown
— 38279 1 .313 x .250 Male Pipe Elbow Not Shown
— 33491 1 .313 x .125 Barb Tite Hose End Not Shown
— 1002917-26 1 Adapter, .250-18 Fp To M14 Not Shown
— 35189 2 Brass Hose Ftg Male Pipe .250 Not Shown
— 33277 2 #4 Hose Clamp .250 to .625 Not Shown
