LeeBoy Model 8510B Conveyor Paver 10-77
Illustrated Parts List (IPL)
Instrument Panel Dash - Controls and Gauges Parts List
Item
No. Part Number Qty. Description Remarks
1 1002032 1 Gauge, 3 in 1: Tach, Oil, Water Temp LH Auto Augers
2 31983 1 Light, Red, Dash, .500 Hole
3 1002033 1 Fuel Gauge
4 1002034 1 Volts Gauge
5 1002035 1 Hourmeter Gauge
6 851391 1 Switch, Toggle, SPST, 2-POS
7 851391 1 Switch, Toggle, SPST, 2-POS
8 851391 1 Switch, Toggle, SPST, 2-POS
9 851391 1 Switch, Toggle, SPST, 2-POS
10 851391 1 Switch, Toggle, SPST, 2-POS
11 851391 1 Switch, Toggle, SPST, 2-POS
12 39146-14 1 Ignition Switch w/Heat Start
13 851391 1 Switch, Toggle, SPST, 2-POS
14 851391 1 Switch, Toggle, SPST, 2-POS
15 982249 1 Switch, Push Button
16 900030 2 Switch, Toggle
17 900030 2 Switch, Toggle
18 900080 1 Switch, Toggle, 3-Pos, Rev-DPDT, MOM
19 39146-14 1 Ignition Switch w/Heat Start
— 982008-04 2 Ignition Key, Replacement Not Shown
20 31985 1 Light, Green, Dash, .500 Hole
21 851391 1 Switch, Toggle, SPST, 2-POS
