LeeBoy Model 8510B Conveyor Paver 10-89
Illustrated Parts List (IPL)
Extension Double Adjust LH Assembly - Propane Parts List
Item
No. Part Number Qty. Description Remarks
1 983409-1SRV 1 Assy, Insert, Propane, LH Without Slope
2 988318SRV 1 Assy, Heat Box, Propane, 4 Adjust
3 1002735 1 Hinge Assy
4 985556 1 Assy, Slide Adjust
5 870030 4 Bearing, Screed Flight Screw
6 851185SRV 1 Ext Adj Screw Assy
7 870279 4 CSSH, .375-16 Shldr Socket
8 1002715 1 Adjuster Mount
9 143-3 4 Nut, .375-16 Lock
10 854447 1 Rnd, .688 x 43.50, CRS
14 988292 1 Assy, Heat Box Cover, 4 Adj
15 851180LSRV 1 Guard, LH Screed Ext Hinge
16 80230 3 CSHH, .375-16 x 2.00
17 119-4 3 Washer, Lock, SAE, .375
18 118-1 22 Washer, Lock, .250
19 80185 22 CSHH, .250-20 x 1.00
20 851600-1 A/R Ext. Burner Pipe
