LeeBoy 8510b - Page 267

10
LeeBoy Model 8510B Conveyor Paver 10-103
Illustrated Parts List (IPL)
Extension Single Adjust LH Assembly - Electric Parts List
Item
No. Part Number Qty. Description Remarks
1 985561SRV 1 Assy, Insert, Electric, LH
2 987872SRV 1 Assy, Heat Box, Elec, Single Adj
4 851185SRV 1 Ext Adj Screw Assy
5 870030 1 Bearing, Screed Flight Screw
6 870279 1 CSSH, .375-16 Shldr Socket
8 854447 1 Rnd, .688 x 43.50, CRS
9 987890SRV 1 Element, Heater, Screed, 40”
9a 985699-03 1 Wiring, Element, Heater Pigtail
10 985120 1 Bar, .250 x 1.50 x 36
11 985123 4 Clamp, Element, Screed Ext
12 988291 1 Assy, Heat Box Cover, Single Adj
13 118-3 22 Washer, Lock, .375
14 81068 22 CSHH, .375-24 x 1.00, GR8
15 987396 1 Nut, .875-9 UNC-2B Nylon Lock
16 851180LSRV 1 Guard, LH Screed Ext Hinge
17 860048 3 CSHH, .437-14 x 1.25, GR5
18 116-4 3 Nut, .437-14 Hex
