5
LeeBoy Model 8510B Conveyor Paver 5-9
Component Location
Table 5-3. Speed and Steering Control Module - Joysticks
ITEM NO. CONTROL NAME FUNCTION
1 Right Steer/Left Steer
Joysticks
Lever controls the speed and direction of travel forward and reverse. Moving
joystick forward moves machine forward. The farther forward the faster the
speed. Moving joystick backward moves machine backward. The farther
backward the faster the speed. When Joystick is centered, the machine is in
neutral.
NOTE: Machine must be in neutral to start machine.
NOTE: You can only use one steering control module at a time. When
steering paver with control module the RUN/STOP Switch (Figure
6-1,4; Figure 6-1,3) must be in RUN position on the module in use
and STOP position on the other module not in use.
2 Run/Stop Switch The RUN/STOP switch controls stopping the machine and activating/
deactivating the operator control station. When the switch is set to the STOP
position, operator control station is deactivated, parking brake is applied,
and machine will not move. When switch is set to RUN, operator control
station is activated, parking brake is released, and machine resumes to
previously set speed.
NOTE: Only one operator control station can be active at a time (see
Activating and Deactivating Operator Control Station in Section
6).
NOTE: If the position of the joystick(s) has NOT changed from when the
RUN/STOP switch is moved to the STOP position and then later
switched to the RUN position, then paver will resume travel at the
same speed of travel when the switch is set to the RUN position.
If the position of the joystick(s) HAS changed from when the RUN/
STOP switch is moved to the STOP position then later switched
to the RUN position, the paver travel function will be temporarily
disabled until joysticks are returned to the NEUTRAL position.
