5
LeeBoy Model 8510B Conveyor Paver 5-15
Component Location
Table 5-6. Paving Controls
ITEM NO. CONTROL NAME FUNCTION
1 Auger Remote Control
Head
Used for adjusting the height of material at End Gate. Connected to Sonic
Auger Adjustment
2 Flight Screw Sets the depth of the asphalt
3 Endgate Depth Screw Controls the depth of the endgate
4 Igniter Used to light the burners
5 Crown and Valley Allows the screed to bend in the middle for crown and valley
6 Sonic Auger Sensor
Mount
Mounting bracket for Sonic Auger
7 Hydraulic Oil Sight/
Temperature Gauge
Monitors the level and temperature of the hydraulic uid
8 Conveyor Drive Chain
Adjustment
Screws with jam nuts for adjusting the conveyor drive chain tension
9 Spray Down Hose Used to lubricate and keep asphalt from hardening on the machine
