LeeBoy Model 8510B Conveyor Paver 5-17
Component Location
Table 5-7. Electric Screed Operation Controls
ITEM NO. CONTROL NAME FUNCTION
1 Sonic Auger Sensor Connected to Sonic Auger Adjustment. For reference only.
3 Screed Vibrator Provides vibration to screed frame for better mat compaction.
4 Heat Control Box Has a power switch (Figure 6-8,1), a START HEAT button (Figure 6-8,2),
and a heat cycle indicator light (Figure 6-8,3). Houses element breakers.
5 Crown & Valley Adjuster Adjusts for positive crown or negative valley in wear plate.
6 Flight Screw This screw controls the depth of the asphalt.
7 End Gate Tilt Screw Used to adjust the tilt on End Gate.
8 Adjustment Screw Adjusts the back end of the front of the extension.
9 End Gate Depth Screw This control sets the depth of the End Gate.
10 Sonic Auger Sensor
Mount
Holds the Sonic Auger Sensor in proper position to maintain the proper
height of augered material.
11 Crown & Valley
Indicator
Shows the amount of crown in screed.
