125
02/10/2013MM00496-b-
H4649
LN4649
0 675 65
5 727 35
5 722 35
2 3
4
5 6
1
DC - In
SCS
E49
PRI: 220 – 240 V~
185 – 175 mA
50/60 Hz
SCS: 27 Vdc
600 mA
MH201
MODE
+
–
FAN
DND
MUR
R1 = 2
R2 = 7
M = 2
L = 0
A = 1
PL = 1
T = 2
R1 = 2
R2 = 7
M = –
A = 9
PL = 8
M = CEN
LED = –
A = 9
PL = 9
M1 = CEN
DEL1= –
M2 = –
DEL2= –
ZA = 2
ZB = 7
N = 1
LOAD = –
ZA = 2
ZB = 7
TYPE = 1
HEAT = 7
COOL = CEN
PUMP = –
IN = 3
MH201
E49
3513
230 V
50 Hz
L
N
H4650
LN4650
0 675 90
230 Vac
H4649
LN4649
0 675 65
5 727 35
5 722 35
H4653
LN4653
0 675 93
H4652
LN4652
0 675 92
F430R8
L
N
H4691
LN4691
0 674 59
B C
D
E
A
F
LL1
EN
BUS-SCS
key card switches
Wiring diagrams
To other
room services
HUB Switch
Other rooms
PC for room management
WINDOW
OPEN
ON
ECO
Ethernet
network
Ethernet
network
Principle and configuration diagram for a hotel room
WINDOW
CLOSED
Bell
12 Vac/dc – 230 Vac
max 1A
Transformer
Protection
line
NC contact
Magnet
Magnet
Contact
Contact
To the fan-coil
or temperature
control system
BUS SCS
To other
devices
A
The general switch GS (TM+EL) must
be selected based on the absorption of
the services installed.
B
The TM switch must be selected based
on the power supply used.
C
D
The TM switch must be selected based
on the loads connected.
E
The actuator to be used depends on
the type of air conditioning system
installed.
F
If the current supplied by the E49
is not sufficient to power the SCS
system, it is possible to use the
E46ADCN power supply.
ITEM DESCRIPTION
E49 Power supply
LN4650 Outside the door indicator
LN4649 Key card switch
LN4653 DND and MUR controls
LN4652 8 key scenario control
LN4691 Thermostat with display
MH201 IP scenario module
F430R8 Air conditioning actuator
General note: the devices listed in the legend are for
the LivingLight series.
CORRIDOR
RECEPTION
ROOM
N
L
V1
V2
V3
Heating
Cooling
TM3
TM1TM2
GS
(TM+EL)
