LEGRAND 3440 - Am5742

456
A
PF
M2
M1
LEFT
RIGHT
+-
+-
1 2 7
4 3 5 6
L4562
067555
H4562
AM5742
Description
This device amplies the stereo signal on the BUS and controls up to two loudspeakers
with impedance between 8-16 Ω. On the front the amplier has two pushbuttons which
can: switch the loudspeakers ON/OFF, adjust the volume in output, change the audio
source and cycle the saved stations (for the radio) or change the CD tracks. Correctly
congured the amplier can have two modes:
- “FOLLOW ME” mode: function which allows the same music in another room after the
amplier of the room previously occupied has been switched o and switching on the
amplier on the room you are now in.
- “NO FOLLOW ME” mode: when another amplier is switched on, on changing room,
the source congured the same as the congurator (inserted on M2) inserted on the
amplier switches ON, not necessarily the source which was being listened to before.
By using the “+” input of one channel and the “-” input of the other channel, it is possible
to install only one loudspeaker and create a monophonic system.
Related articles
Axolute, LivingLight button covers
1-module button covers art. L/N/NT4911... (art. L4562) or art. HC/HD/HS4911... (art. H4562)
Arteor button covers
5739 66, 5739 64 (White cover)
5739 67, 5739 65 (Magnesium cover)
Céliane button covers
682 63, 682 64 (White cover)
685 63, 685 64 (Titanium cover)
680 83 (White front nishing frame)
683 83 (Titanium front nishing frame)
Technical data
Power supply: 18-27 Vdc
Max. absorption: 250 mA with 8 Ω loudspeaker on 2 L-R outputs
130 mA with 8 Ω loudspeaker on 1 L-R output
130 mA with 16 Ω loudspeaker on 2 L-R outputs
90 mA with 16 Ω loudspeaker on 1 L-R outputs
40 mA (MUTE)*
Absorption in stand-by: 6 mA
Operating temperature: 5 °C - 45 °C
Power (on 8Ω): 2 Wrms (1 Wrms+1 Wrms)
16 Wpmpo (8 Wpmpo+8 Wpmpo)
TYP channel balancing: ± 0.5 dB
MIN channel balancing: ± 1.5 dB
Frequency range @ -3 dB: 20 Hz–20 kHz
TYPS distortion: 0.1%
Noise signal ratio: 68 dB
* take into account this value when the Sound system is integrated with the 2-WIRE
video door entry system.
Conguration
A: 1-9 address of the amplier room
PF: 0-9 amplier address
M2: - (no congurator) when the amplier is switched on, the last source which
was on is activated, “FOLLOW ME” mode
1-4 when the amplier is switched on, the source with the same conguration
as that set on the device itself switches on (example amplier with M2=2,
in this case the source with S=2 will switch on), “NO FOLLOW ME” mode.
Dimensional data
Size: 2 modules
Legend
1. control to switch on the amplier (simple touch) and increase the volume
(extended pressure)
2. control to cycle and activate the available stereo sources
3. control to scan the stations saved (for the radio)
4. control to switch o the amplier (simple touch) and decrease the volume
(extended pressure)
5. screw clamps for connection of the loudspeakers
6. removable clamp for BUS connection
7. congurator socket
Flush mounted stereo amplier
MQ00008-c-EN 05/06/2014
