190
H4671/1 L4671/1
AM5851/1
Flush-mounted 1-relay actuator
MQ00072-e-EN 05/06/2014
NOTE 1): Only for point-point control. With the OFF control the Master actuator deactivates; the
Slave actuator deactivates after the time set on the Master actuator has elapsed. Typical function
for use in bathrooms without windows where the ON control activates the light (Master actuator)
and the ventilation fan (Slave actuator) at the same time. The OFF control switches the light off im-
mediately and leaves the fan working for the time set with configurator 1 to 4 in M of the Master
actuator as indicated in the table. The control must be configured in socket M = 0/1.
1.2 Mode
Virtual configuration (MYHOME_Suite) / Physical configuration
Function Parameter / setting
Master Actuator - Cyclical ON/OFF M=0
ON with top button, OFF with bottom button M=O/I
Actuator as Slave. Receives a command sent by a
Master actuator with the same address
M=SLA
Pushbutton (ON monostable) ignores Room and General controls M=PUL
Master Actuator with OFF control delayed on the corresponding
Slave actuator.
1)
M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
Use 2-module button cover with dual function
