H4678
L4678
Dimmer actuator 300VA
MQ00075-d-EN 05/06/2014
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 1-9 A=1-9
Lighting point 1-9 PL = 1-9
Groups
G=0-9 G=0-9
NOTE 2): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. Only for point-point control.
With the OFF control the Master actuator deactivates; the Slave actuator deactivates after the time
set on the Master actuator has elapsed. Typical function for use in bathrooms without windows
where the ON control activates the light (Master actuator) and the ventilation fan (Slave actuator)
at the same time.
The OFF control switches the light off immediately and leaves the fan working for the time set with
configurator 1 to 4 in M of the Master actuator as indicated in the table.
1.2 Mode
Virtual configuration (MYHOME_Suite) and physical configuration
Function Parameter / setting
Master Actuator (Cyclical ON/OFF) M=0
ON with top button, OFF with bottom button.
1)
M=O/I
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
M=SLA
Pushbutton (ON monostable) ignores Room and General controls M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
2)
M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
NOTE 1):
Use 2-module button cover with dual function
