Conguration
Double-technology detectors require assignment of the appropriate zones and the
progressive number of the sensors in the zone, setting of the detection mode and
possibly assignment of an auxiliary prealarm channel.
Z
This configurator assigns the number of the appropriate zone to the detector.
Configurator 1 assigns zone 1 to the detector, configurator 2 assigns zone 2 and so on to
a maximum of 8 zones.
N°
This configurator assigns the progressive number of the detector inside the appropriate
zone. Configurator 1 identifies the first detector, configurator 2 identifies the second and
so on to a maximum of 9 sensors (IR detectors and contact interface) for each of the 8
zones.
MOD
This congurator sets the sensor detection mode.
It can be used, for example, when the device is directed towards a possible source of
disturbance (window or radiator), and its position cannot be changed.
Congurator Mode
0 1
st
sensitivity level
2 2
nd
sensitivity level
3 3
rd
sensitivity level
4 1st sensitivity level with delay.
6 2
nd
sensitivity level with delay.
7 3
rd
sensitivity level with delay.
AUX Activation of the pre-alarm function, irrespective of
the system status (armed or disarmed). The device
sends an auxiliary type alarm through the specied
channel in the AUX position. If the zone it belongs to is
separated, the auxiliary command is disabled.
Congurator position Value
Z 2
N° 1
MOD none
AUX none
Example
Example of IR detector with auxiliary conguration. First sensor belonging to zone 2,
and with high sensitivity, and pre-alarm on auxiliary channel no. 3 with the system
disarmed (e.g. activation of bell when someone goes through the area).
With the system armed, the device only operates as burglar-alarm sensor.
Congurator position Value
Z 2
N° 1
MOD none
AUX 3
High sensitivity (1
st
level) = maximum coverage 8 metres
Medium sensitivity (2
nd
level) = maximum coverage 6 metres
Low sensitivity (3
rd
level) = maximum coverage 3 metres
AUX
If the AUX congurator has been installed in the MOD position, the 1 to 9 value of the
congurator in this position activates the pre-alarm function, assigning the 1 to 9
number of the auxiliary channel.
If no congurator, or one of the 2 to 7 congurators, are present in the MOD position, the
device only activates the pre-alarm function when the system is disarmed.
Note: to complete the activations using the relay actuator type F or 3479, see the
appropriate technical sheet.
EXAMPLE
First sensor belonging to zone 2.
Double technology
IR+MW detector
