288
PL
A
G1
G2
M
14
L L1
14
O
N
5
N4640
N4640B
Conguration N4640
AUTOMATION mode – TIMED CONTROL:
Passive IR detectors can generate and send an ON timed control directly to one or more
actuators.
For this mode, congure in the Z and N positions of the detector the addresses A and PL
of the actuator to control respectively.
To the
position connect the ON congurator to enable the time delay function.
The switching ON period is set by connecting numerical congurators 1 to 9 to the AUX
position as shown in the following table:
AUX 1 2 3 4 5 6 7 8 9
Time 1 min. 2 min. 3 min. 4 min. 5 min. 15 min. 30 sec. 0.5 sec 2 sec.
Example of conguration
AUTOMATION mode – GENERIC CONTROL USING AUXILIARY CHANNELS:
In this case, the actuator is managed by a control device, item H/L4651M2 or AM5831M2,
which, based on its own operating mode, set in its own M position, activates the actuator
with address set in A and PL.
The communication between the detector and the associated control device item H/
L4651M2 or AM5831M2 is established by dening an auxiliary channel that has been
congured in the IR detector by connecting the AUX congurator to the
position,
and specifying, with numeric congurators 1-9 in the AUX position, the number of the
auxiliary channel. Obviously, in order to univocally establish the auxiliary channel, also
the AUX position of the control must have the same congurator as the IR detector.
Actuator
IR detector
item L4671/1
Passive IR detector
MQ00038-d-EN 04/06/2014
