294
RISCALDAMENTO
BUS
1 2 3
4
5 6
7 8 9
0
OK
T
-
1C
-
2C
T
1C
2C
}
}
T1
T2
T = 10 x 100 = 1000 sec
3455
chiller
switching
valve
integration
boiler
probe
interface
actuator
99-zone
central unit
Setting the temperature update interval
The radio probe sends the “temperature” reading to the receiving interface at regular
intervals that can be manually set using the jumpers, which must be connected to the
T1 and T2 sockets. The update time is calculated following the formula below: T=T1xT2.
The correspondence between the settable times and the jumpers is shown on the
table. When the factory settings are used, the temperature will be updated every 1000
seconds. A change in the factory settings will also entail a variation on the solar cell
recharging time, or the duration of the battery (if applicable).
Jumper sockets
Factory settings
Automations - system with integration boiler
Jumper/time table
Jumpers T1/T2
1 sec.
10 sec.
100 sec.
MQ00182-c-EN 29/04/2014
Radio outdoor
temperature probe
