340
F521
To configure the measured phase, use MYHOME_Suite virtual configuration
NOTE (*): The reference value for the load control thresholds is that of the contractual power in
kW. The Ampere value can be used as a general indication to help the installer in those cases when
the service provider supplies the current information.
MQ00360-c-EN 09/06/2014
Load control central unit
1.2 Contractual power
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting P Contractual power
P
NOM
(kW)
Approximate value in
Amperes at 230 Vac
*)
Contractual power (Pnom) 100 W - 25500 W (steps of 100)
0
3 13
1 1.5 6.5
2 4.5 20
3 6 26
4 9 40
5 10.5 46.5
6 12 52
7 14 61
8 15 65
9 18 78
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Address 1-127 A1, A2, A3: 1-127
1.3 Contractual power tolerance
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting TOL Tolerance
Contractual power tolerance From -20% to +20% (steps of 1%) 0 0
1 -5%
2 -10%
3 -15%
4 -20%
5 5%
6 10%
7 15%
8 20%
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
- Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in
this sheet and to the "Function Descriptions" help section in the
MYHOME_Suite software package.
The load control central unit has a bay for five configurators, which define:
- A1/A2/A3 address o
f the central unit (A1 for hundreds, A2 for tens, A3 for units);
The maximum number of addresses is 127.
- P contractual power Pnom
- TOL Tolerance
Configuration
