481
F420
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
- Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com.
For a list of the procedures and their meanings, please refer to the instructions in
this sheet and to the "Function Descriptions" help section in the
MYHOME_Suite software package.
The combination of the scenario module with a control device is ensured by assigning to
both items the same address. This is identied by the congurators with a numeric value
for position A = 0-9 and position PL = 1-9. Several scenario modules may be installed in
one system, allocating a dierent address to each module.
Scenario programming
In order to program, change or cancel a scenario, it is necessary to enable the
programming mode of the Module item F420 so that the status LED is green (press the
lock/unlock key on the Scenario Module for at least 0.5 seconds); continue with the
following operations:
1) Press one of the four scenario control keys the scenario should be paired with for 3
seconds. The corresponding LED starts ashing.
2) Set the scenario using the corresponding controls for the various Automation,
Temperature control, Sound system, etc. functions.
3) Conrm the scenario by quickly pressing the corresponding key on the control to exit
programming mode.
4) To change or create new scenarios to be linked to the other keys, repeat the procedure
starting from point 1.
To recall an already set scenario, briey pressing the corresponding button on the control is
enough.
If the module does not receive any input for 30 minutes from the start of the learning
procedure, programming will automatically be interrupted. If you want to delete a scenario
completely, press and hold down the corresponding button for approximately 10 seconds.
To erase the entire memory keep the DEL pushbutton on the Scenario module pressed for
10 seconds, the yellow “reset scenarios” LED ashes quickly. Once the operations have been
performed lock the programming by pressing the lock/unlock pushbutton for at least 0.5
seconds, so that the corresponding LED becomes red.
NOTES:
Inside the system itself one Scenario module can be programmed at a time as the other
devices are temporarily locked; during this phase the “programming status” LED becomes
orange signalling the temporary Lock. During the learning procedure and when there
are timed controls or group controls, the Scenario module does not save events for 20
seconds. You must thus wait before continuing with creating the scenario. During the
scenario learning procedure only the changes of status are saved. It is important to
congure the scenario module with a dierent A and PL address to that of an actuator.
If the conguration is wrong the Programming status LED ashes ORANGE. In case of
“virtual” conguration the LED ashes RED.
Configuration
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-9 A=0-9
Lighting point 1-9 PL = 1-9
Scenario Module
MQ00067-d-EN 05/06/2014
