Basic contacts interface
9. Sound system control
This mode allows you to control the amplifiers and the sources of the Sound System.
9.1 Addressing
You can manage a single amplifier (point-to-point control), some amplifiers (room control) and all the amplifiers in the system (general control).
Virtual configuration (MYHOME_Suite) Physical configuration
Addressing type Parameter / setting
Point-to-point Room 0-9 0-9
Sound point 0-9 0-9
Room Room 0-9 A=AMB
PF=0-9
General General A=GEN
9.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Type of contact to terminals PL1 and PL2 Normally open (N/O) SPE=0
Normally closed (N/C) SPE=7
ON/volume + SPE=5 , M=0 (for button on PL1)
OFF/volume - SPE=5, M=0 (for button on PL2)
Change track SPE=5, M=1 (for button on PL1)
Click on source SPE=5, M=1 (for button on PL2)
For the “Cyclical ON/OFF” function and to select sources 1-9 use the MYHOME_Suite vir-
tual configuration
Follow Me mode
Enables, upon powering the amplifier, activating the last source switched on.
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Switch back on from the last source YES YES M=0
NO Definition of the source 1-4 M=1-4
1)
NOTE 1): indicates the sound source to be activated before switching on the amplifier.
