61
BMSW1002
SCS actuator 2x16A
MQ00312-f-EN 09/06/2014
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the MYHOME_Suite software
package.
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2 = 1-9
Groups
Group 1 - Group 10 = 0-255 G1, G2 = 0-9
NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. With the OFF control
the Master actuator deactivates; the Slave actuator deactivates after the time set with the
configurators has elapsed. Typical function for use in bathrooms without windows where the ON
control activates the light (Master actuator) and the ventilation fan (Slave actuator) at the same
time. The OFF control switches the light off immediately and leaves the fan working for the time
set with configurator 0 to 4 in M of the Master actuator as indicated in the table. This mode is only
operative if PL1≠PL2.
WARNING: The PL1 and PL2 positions must never have the same configurator
2.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
To use the "Actuator as a slave with PUL function", to select the "Type of load" (Actuator,
Lamp, Valve, Differential Reset, Fan, Irrigation, Controlled Outlet, Lock) use MYHOME_
Suite virtual configuration.
When installed in a Lighting Management system, the device can be configured in the
following ways:
- Push & Learn: procedure for pairing different connected devices or changing the
assignments defined automatically in the Plug & Go procedure. For more details, please
refer to the specific document.
- Software Configuration: using the Virtual Configurator software; for more details, please
refer to the specific manual.
Configuration
1. Lighting Management System
2. My Home system
