Safety measures and precautions
23
Data from tractor operating instructions
 Take the following data from your tractor's operating instructions:
Abbreviation Data
T
L
Tractor kerb weight (kg) _______ kg
T
V
Front axle load (kg) of empty tractor _______ kg
T
H
Rear axle load (kg) of empty tractor _______ kg
Data from implement operating instructions
 Take the following data from these operating instructions or from the documents
for the front weight or rear weight:
Abbreviation Data
G
H
Gross weight (kg) for rear mounting implement or
rear weight
_______ kg
G
V
Gross weight (kg) for front mounting implement or
front weight
_______ kg
d Distance (m) between centre of lower control link
ball and centre of gravity for rear mounting imple-
ment or rear weight
_______ m
Data to be determined through remeasuring are
 Determine the following data through remeasuring:
Abbreviation Data
a Distance (m) between centre of gravity for front
mounting implement or front weight and centre of
front axle
_______ m
b Tractor wheelbase (m) _______ m
c Distance (m) between centre of rear axle and centre
of lower control link
_______ m
