LEMKEN Juwel 7 - Working Width for each Base; Juwel V

Adjustments
55
10.7 Working width for each base
10.7.1 Juwel V
Once the basic plough settings have been
made with the OPTIQUICK adjusting cen-
tre, the working width for each base can be
changed as required from the tractor seat
using the working width adjusting cylinder
(1).
 Smaller working width => Extend piston
rod (2)
 Larger working width => Retract piston
rod (2)
The set working width is indicated on the
scale (3).
3
1
2
