Adjustments
49
Re-tighten the clamping screw (2), see
«Tightening torques, page 86».
Retract the hydraulic cylinder again.
The connection T1 of the rotary cylinder
is pressurised.
10.1.4 Front furrow width, hydraulic
In place of the outer spindle, a hydraulic
cylinder (1) with installed sensor is used
via which the front furrow width can be set
hydraulically.
The front furrow width must be set so that the working width cor-
responds to the following plough bodies.
The front furrow width is set from the tractor seat using a button
via the control unit, which is also used for the turning.
A
1
2
1
