Preparations on tractor
37
6.6 Required hydraulic equipment
The implement is supplied as standard with separate hydraulic connections for
each consumer. The protective caps for the hydraulic connections are colour-
coded and the hydraulic connections themselves are alphanumerically coded.
For operation of the specific hydraulic equipment listed below, the tractor must be
equipped with the following control units:
Consumers Double-acting
Turnover ram
Hydraulic angular adjustment
Hydraulic front furrow width adjustment, if fitted
Hydraulic overload protection, standard design
1
Hydraulic working width adjustment (Juwel V) 1
Hydraulic overload protection, comfort design 1
Hydraulic depth and transport wheel 1
