LEMKEN Juwel 7 - Tractor Ploughing Line

Adjustments
50

Press the yellow button (2). The LED in
the button lights up.
 During ploughing, set the desired front
furrow width via the control unit.
If the desired width has been reached, you
have two options:

Store the front furrow width:
 Hold the button (2) pressed for at least 3
seconds until the LED goes out.
 Set the front furrow width one time:
 Press the button (2) briefly. The LED
goes out when the button is released.
10.2 Tractor ploughing line
The tractor ploughing line must be set us-
ing the inner spindle (2) so that there is no
more lateral pull.
 Tractor pulls towards ploughed land:
 Move the slewing gear towards the
ploughed land with the inner spindle (2).
 Tractor pulls towards unploughed land:
 Move the slewing gear towards the un-
ploughed land with the inner spindle (2).
