LEMKEN Juwel 7 - Swivel Limitation

Adjustments
63
10.12.4 Swivel limitation
The swivelling range to the side of the disc
coulter is set with the screw (9).
 Loosen the screw (9).
 Move the stop (10) into the required po-
sition.
 Re-tighten the screw (9), see
«Tightening torques, page 86».
 Once the setting has been made, the screws and nuts loosened
must be re-tightened.
 Never reset the implement as long as there are still, coulters in
the ground.
9
7
8
10
