Adjustments
59
10.10 Trashboard

Screw the trashboard (1) and retainer (2)
onto the base blade (3).
The retainer (2) has slots (4) to allow uni-
versal adjustment.
10.11 Landside coulter

Remove the landside wedge (1) before
retrofitting the landside coulter.
2
4
1
1
2
3
