Preparations on tractor
38
6.6 Hydraulic equipment required
The implement is supplied as standard with separate hydraulic couplings for each
consumer. The protecting caps on the hydraulic couplings are coloured and the
hydraulic couplings themselves are marked alphanumerically.
The following spool valves must be available on the tractor in order to operate the
individual hydraulic devices listed below:
Load Double-acting
Turnover ram
Hydraulic inclination adjustment
Hydraulic front furrow adjustment, if fitted
Hydraulic overload protection, Standard version
1
Hydraulic working width adjustment (Juwel V) 1
Hydraulic overload protection, Comfort version 1
Hydraulic Uni wheel 1
Hydraulic on-land swivelling* 1
Integrated FlexPack furrow press 1
* Hydraulic on-land swivelling is only available in combination with hydraulic working width
adjustment and hydraulic frame swivelling.
