LEMKEN Juwel 8 - Attachment Arm

Attachment arm
95
13 ATTACHMENT ARM
BEWARE
 Read and follow the “Safety and protection measures”, page 13.
The attachment arm pivots into the catch position as a result of
spring tension.
 Ensure that you maintain an adequate safety distance.

Push the attachment arm (1) at the front
of the plough frame into the recess (2).
 Secure it with the pin (3).
 Connect the hydraulic lines.
See the operating instructions for the rele-
vant attachment arm.
3
1
2
