LEMKEN Juwel 8 - Front Furrow Width, Hydraulic

Operation
58
11.4.4 Front furrow width, hydraulic
A hydraulic cylinder (1) with built-in sensor
is used instead of the outer spindle to hy-
draulically adjust the front furrow width.
The front furrow width must be set to correspond to the working
width of the following plough base.
The front furrow width is adjusted from the tractor seat using a
button on the control unit, which is also used for turning.

Press the yellow button (2). The LED on
the button lights up.
 Set the desired front furrow width using
the control unit during ploughing.
When the desired width is reached, you
have two options:
 Save this front furrow width:
 Hold down the button (2) until the LED goes out = min. 3 seconds.
 Set the front furrow width once:
 Briefly press the button (2). When you release it, the LED goes out.
1
2
