Uncoupling the implement
47
 Raise the plough.
 Pull out the locking bar (3) with a twisting
motion.
 Pivot the stand (2) downwards.
CAUTION
Risk of injury when the stand pivots downwards

Release the locks on the lower links.
 Lower the plough.
 Check that the lower links are discon-
nected from the cross shaft.
DuraMaxx
Ensuring that the plough is is a stable
position
When setting down a plough with subsoil-
ers, remove the subsoilers (8) on the lower
side as follows.
 Release the locking bar (9) with a twist-
ing motion.
 Pull the subsoiler (8) out.
 Insert the subsoiler (8) into the holder
(10) from above.
 Secure the subsoiler (8) with the locking
bar (9).
2
3
9
8
10
