Operation
79
Swivel the locking pin (6) on the front of
the turnover device through 180°.
Important: Always carry out the steps in the order specified.
Never change the working width while the plough is in a turning
position.
Raise the plough.
Set the plough to the smallest working width. (Juwel 8M V)
Turn the plough slowly until you hear the locking pin (8) engage.
Check that the locking pin (8) is engaged correctly.
Lower the plough using the hydraulic system.
Disconnect the top link from the headstock.
Raise the front of the plough = transport position.
6
