Operation
84
Hydraulically dampened Uni wheel
Uni wheel hydraulically dampened
Remove the linch pin (3).
Remove the pin (2).
Fix the stop (1) in the required position
using the pin (2).
If finer adjustment is required, the position
of the stop (1) can be changed.
Turn the stop (1) round.
Secure the pin (2) with a linch pin (3) af-
ter every adjustment.
After changing the working depth, it is advisable to adjust the trac-
tor hydraulics setting in addition to the length of the top link and
the tilt setting so that the change does not result in increased slip-
page or poorer depth control.
3
2
1
