Operation
89
O operation
Distance between the tractor and the
furrow edge
Set the distance between the tractor and
the furrow edge using the inner hydraulic
ram (2).
Distance too short
=> Retract the hydraulic ram (2).
Distance too long
=> Extend the hydraulic ram (2).
Side pull correction / tractor/plough pull
line adjustment
Set the tractor/plough pull line using the
hydraulic ram (3).
Tractor pulls towards the ploughed land
 To retract the hydraulic ram (3), press
the yellow button (6) (LED lights up).
Tractor pulls towards the unploughed land
 To extend the hydraulic ram (3), press
the yellow button (6) (LED lights up).
 Press and hold the yellow button (6) for
approx. 4 seconds = save the setting.
2
3
3
6
