LEMKEN VariOpal - Axle Load Management

Preparation of the Tractor
15
3.6.1 VariOpal (X, HX) – Manual hydraulic plough control system
Required control units
Single-acting Double-acting
Double-acting connection - 1
Single-acting with return
connection to
oil tank* / **
1 -
With Vari Stop** - 1
With Vari Stop plus - 2
Slewing cylinder
With hydraulic tilt adjustment 2
Hydraulic working width adjustment - 1
Memory cylinder - 1
Driver arm connected to reversing cylinder - -
Driver arm connected straight to control unit 1 -
Hydraulic overload protection - 1
Hydraulic uni wheel - 1
3.6.2 VariOpal OF (X) – Manual hydraulic plough control system
Required control units
Single-acting Double-acting
Double-acting connection - 1
With Vari Stop** - 1
With Vari Stop plus - 2
Slewing cylinder
With hydraulic tilt adjustment 2
Hydraulic working width adjustment - 1
Frame swing-in - -
Driver arm connected to reversing cylinder - -
Driver arm connected straight to control unit 1 -
Hydraulic overload protection - 1
Hydraulic uni wheel - 1
Hydraulic on-land horizontal swing *** - 1
