Overload Safety Devices
55
9.2 Semi-Automatic Overload Safety Device HX
The mounted reversible ploughs of the HX-
range are equipped with a semi-automatic
overload safety device.
It is a compact device with hooks (1), roller
(2) and springs (3, 4 and 5) located inside
the leg bracket (6). The mechanism trips
when the body touches an obstacle.
To re-load, simply lift the plough and allow
the tripped leg to fall back into working po-
sition.
• In the area of the legs (7) and leg brackets (6) there are pinch
points. Keep distance!
6
7
3
5
2
7
1
4
6
