Adjustments
44
8.7.4 Conversion to the front or rear
By means of re-positioning the skim stalk
(4) or the bracket of the angle adjustment
to the front or rear, the position of the
skimmer (1) can be optimised.
To the rear = more clearance between
skimmer and the plough
body fitted in front.
To the front = more clearance between
skimmer and the plough
body that goes with it (e.g.
to prevent clogging of
stones).
8.7.5 Tail pieces (for D1 and M2, only)
The tail pieces (2) will be connected to the
corresponding bores of the skimmers (1)
via the slotted holes. They are universally
adjustable and support the work of the
skimmers.
1
4
2
1
