Use
18
4 USE
4.1 General Instructions
Before the first use it is recommendable - with fully lowered implement - to carry
out the following adjustments at the farm. Afterwards only few adjustment correc-
tions have to be carried out in the field.
4.2 Top Link Connection
Connect top link to headstock (1) and en-
sure that the top link rises slightly towards
the plough.
In hilly conditions use the slotted hole (2)
with ploughs having 5-furrows or more.
Important! When the top link is connected to the slotted hole (2)
the top link pin (3) must always be positioned in front
of the slotted hole (2) and the top link must always be
tension loaded during work.
1
3
2
