Adjustments
45
8.8 Trashboard
Fit trashboard (1) with holder (2) to the
mouldboard (3). The holder is provided
with slotted holes (6) which allow an uni-
versal adjustment.
Adjust support-bolt (4) so that it touches
the leg.
Secure support-bolt (4) by means of the
counter nut (5). The counter nuts must be
tightened for work.
8.9 Sword Coulter
Fit sword coulter (1) in front of the land-
slide (2) of the plough body.
2
3
6
1
4
5
4
5
2
1
