Use
20
4.6 Clearance for the Turnover Operation
Check whether there is sufficient clearance
between plough/depth wheel and ground.
If not, shorten the inner turnbuckle (1), set
drawbar deeper, fit top link to a higher hole
in the headstock or use an hydraulic frame
swing-in assy.
Raise the plough fully and then turn the
plough carefully.
When a Memory ram is fitted, the plough frame can 1
st
be swung-in and 2
nd
the
front furrow width can be adjusted from the tractor seat.
4.7 Skimmers
The skimmers should be set to a depth be-
tween 5 and 10 cm.
If the required working depth of the plough
is 25 cm, the skimmers should be adjusted
so that the distance A between the point of
the skimmer and point of the plough body
amounts to 15 to 20 cm.
1
A
