Subindex 3: Notch filter 1: Damping
Setting range (min. value | unit | max. value) Lenze setting
0 dB 100 0 db
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
Subindex 4: Notch filter 2: Frequency
Setting range (min. value | unit | max. value) Lenze setting
1.0 Hz 1000.0 400.0 Hz
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_16
Subindex 5: Notch filter 2: Bandwidth
Setting range (min. value | unit | max. value) Lenze setting
0.0 Hz 500.0 40.0 Hz
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_16
Subindex 6: Notch filter 2: Damping
Setting range (min. value | unit | max. value) Lenze setting
0 dB 100 0 db
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
