1 About this documentation
1.4 Structure of the parameter descriptions
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter attributes
 Tip!
To find a specific object or parameter in this documentation, you can use the following
navigation helps:
• At the beginning of each main chapter, all objects which are described in the respective
chapter are listed in a table.
•In the Table of attributes
and the Index, all objects/parameters are listed with a
reference to the detailed description.
Name Meaning
Write access  = Parameter can be written to.
 = Parameter can only be read.
CINH  = Parameter can only be written to if controller inhibit is set.
OSC  = Parameter can be recorded by means of the oscilloscope function.
P  = Parameter can be persisted.
Tx  = Parameter can be mapped into the TPDO.
Rx  = Parameter can be mapped into the RPDO.
Data type Data type of the parameter:
INTEGER_8 1 byte, with sign
INTEGER_16 2 bytes with sign
INTEGER_32 4 bytes with sign
UNSIGNED_8 1 byte without sign
UNSIGNED_16 2 bytes without sign
UNSIGNED_32 4 bytes without sign
UNSIGNED_64 8 bytes without sign
STRING(xx) ASCII string (with character length xx)
ARRAY [] OF... ARRAY
Scaling Scaling of the parameter
