8 Monitoring functions
8.5 Motor temperature monitoring
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
-3276.8 °C 3276.7 155.0 °C
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 5: Motor temperature monitoring: Actual motor temperature
Display of the current motor temperature
Display area (min. value | unit | max. value) Initialisation
-666.0 °C 666.0
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 6: Spec. charact.: temperature sampling point 1
From version 01.03
The special thermal sensor characteristic is selected by setting "3" in 0x2D49:1
(or 0x3549:1 for axis B)
Setting range (min. value | unit | max. value) Lenze setting
0.0 °C 255.0 25.0 °C
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 7: Spec. charact.: temperature sampling point 2
From version 01.03
The special thermal sensor characteristic is selected by setting "3" in 0x2D49:1
(or 0x3549:1 for axis B)
Setting range (min. value | unit | max. value) Lenze setting
0.0 °C 255.0 150.0 °C
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 8: Spec. charact.: resistance sampling point 1
From version 01.03
The special thermal sensor characteristic is selected by setting "3" in 0x2D49:1
(or 0x3549:1 for axis B)
Setting range (min. value | unit | max. value) Lenze setting
0 Ohm 30000 1000 Ohm
 Write access  CINH  OSC  P  RX  TX INTEGER_16
Subindex 9: Spec. charact.: resistance sampling point 2
From version 01.03
The special thermal sensor characteristic is selected by setting "3" in 0x2D49:1
(or 0x3549:1 for axis B)
Setting range (min. value | unit | max. value) Lenze setting
0 Ohm 30000 2225 Ohm
 Write access  CINH  OSC  P  RX  TX INTEGER_16
Subindex 4: Motor temperature monitoring: Error threshold

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
