Lenze i700

9 Diagnostics & error management
9.4 CiA402 error codes / error messages
287
Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Error code 0x2380: Fault - utilisation of the power section (Ixt) too high
Text ID: 0x06
Error code 0x2381: Warning - Utilisation of the power section (Ixt) too high
Text ID: 0x07
Error code 0x2382: Fault - device utilisation (Ixt) too high
Text ID: 0x08
Error code 0x2383: Warning - device utilisation (Ixt) too high
Text ID: 0x09
Error code 0x2384: Ultimate motor current reached
Text ID: 0x22
Error code 0x2385: Output current > [value] A (maximum device current)
Text ID: 0x24
Cause Remedies Response
Frequent and too long acceleration
processes with overcurrent.
Check drive dimensioning. Fault
Cause Remedies Response
Frequent and too long acceleration
processes with overcurrent.
Check drive dimensioning. Warning
Cause Remedies Response
Frequent and too long acceleration
processes with overcurrent.
Check drive dimensioning. Fault
Cause Remedies Response
Frequent and too long acceleration
processes with overcurrent.
Check drive dimensioning. Warning
Cause Remedies Response
The motor current has exceeded the
"ultimate" motor current.
The "ultimate" motor current
corresponds to the current level at
which the permanent magnets of a
synchronous motor suffer
permanent damage.
Reduce maximum current
(0x6073
| 0x6873) and/or adjust the
current controller (0x2942
| 0x3142)
in order to reduce the current
overshoot.
Fault
(adjustable in 0x2D46:2
| 0x3546:2)
• Threshold can be adapted in
0x2D46:1
| 0x3546:1.
Cause Remedies Response
The desired maximum current
(0x6073
| 0x6873) is higher than the
maximum current of the axis (display
in 0x2DDF:2
| 0x35DF:2).
The permissible maximum current
(0x6073
| 0x6873) is:
• Setting of rated motor current in
0x6075
| 0x6875.
Warning
Maximum axis current
Rated motor current
-----------------------------------------------------------
